A920 Terminal Overview

This document will introduce you to your payment terminal as well as guide you through the process of preparing and configuring your it in order to quickly begin processing payments.

Your PAX A920 payment processing terminal comes with the following:

  1. Payment terminal

  2. AC power outlet

  3. Roll of printer paper

  4. Charging cable

You may also have an optional charger and external printer included, but this document addresses the most basic delivery configuration.


Terminal Hardware

The following illustrations show the location of the main terminal features and hardware:

  1. Magnetic stripe reader

  2. Front-facing camera (not used)

  3. Color touchscreen

  4. Chip card reader

  5. Volume up button

  6. Power button

  7. Volume down button

  8. Micro USB charging port

  9. Contactless payment reader

  10. Printer

  11. Printer latch

  12. Rear Camera/Scanner

  13. Battery cover
