# Veloce POS Application Configuration

This topic describes how to configure the Veloce POS application to use a PAX terminal as a workstation.

### Veloce POS Application - First start

To start the Veloce POS application, touch its icon on the Android desktop. The app will start, and you will see a welcome screen with the message "Serial number not set".

|                                                                                                                                                                                                                                                                                                                                |                                                                                                                                                                                                                                                                                                                                      |                                                                                                                                                                                                                                                                                                                               |
| ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ | ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ | ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- |
| <img src="https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2F2XCd8DT4QUTyMpT2nvOl%2Fspaces_NjXj7M9eIjDUG86HsSCs_uploads_ZfS9g9DK4qtzrRRXcV6g_03-AppInstalled.webp?alt=media&#x26;token=682682b4-3de1-450b-9db7-507d6f1b845e" alt="" data-size="original"> | <img src="https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2F3zOAYc3T6fOmIvsgZDer%2Fspaces_NjXj7M9eIjDUG86HsSCs_uploads_WMBk9HDti1RBN3mMzIsl_FatArrow-RED.webp?alt=media&#x26;token=0655a5ad-4609-4860-a823-313162fd55e7" alt="" data-size="original">          | <img src="https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2FAUfsPm3z0aA6YxjCVCzo%2Fspaces_NjXj7M9eIjDUG86HsSCs_uploads_ZkZhpaLJmL8R3P6jLfwR_04a-AppStartup.webp?alt=media&#x26;token=b124b3ea-ad5b-4c4e-85b2-d3a901185ddd" alt="" data-size="original"> |
| <img src="https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2Fw2GdrG9wDPbE1ZBgqhJE%2Fspaces_NjXj7M9eIjDUG86HsSCs_uploads_41QdJfUlSAkukTiHtCbA_FatArrow-RED.webp?alt=media&#x26;token=108dac75-6e6c-4e13-8111-15fd542f330f" alt="" data-size="original">    | <img src="https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2Fm0uJ2n3O4tyFtLHR4u7k%2Fspaces_NjXj7M9eIjDUG86HsSCs_uploads_4Z7o0oFgzDJg7jmTffsF_04b-SerialNotSetBLANK.webp?alt=media&#x26;token=9188557f-fccc-46fc-a756-9ed6994ac881" alt="" data-size="original"> |                                                                                                                                                                                                                                                                                                                               |
|                                                                                                                                                                                                                                                                                                                                |                                                                                                                                                                                                                                                                                                                                      |                                                                                                                                                                                                                                                                                                                               |

***

### Veloce POS Application - Initial Configuration

Touch the cog wheel icon in the upper-right corner of the screen to access the application's settings.

![](https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2FuYlhwyZH3iJXMKlqNFWQ%2F04c-SerialNotSetArrow.png?alt=media\&token=cedcd02b-a82e-46bd-a9fc-02d3c6db071e)

The Veloce Application's settings will be displayed. The settings are divided in various sections, illustrated separately for clarity:

***

### Workstation Type

### &#x20;![](https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2Fz6vWqWYzHCDPi1QNoy61%2F04d-WSType.png?alt=media\&token=1f19d694-26b9-44d2-a213-7bfcf4e67cee)

#### Default value

Workstation

#### Available options:

**Workstation**

Select this option to use the payement terminal as a normal POS workstation as well as a payment device.

**Client Display**

Select this option if you are using a tablet as a customer-facing display or order confirmation screen.

**Kitchen Display**

Select this option if you are using a tablet as a kitchen display.

**Terminal**

Select this option to use the terminal as a payment device only.

***

### Workstation Properties

## &#x20;![](https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2FaH1K6hDFmS9Nfwtt7Cji%2F04e-WSOptions.png?alt=media\&token=674ac38e-0f80-449f-b715-fdc80043e99f)

#### Workstation number

Enter the workstation number to use for this workstation. This corresponds to the workstation number configured in Point of Sale Control > Workstation > Workstation's Setup.

#### Serial number

Enter you Veloce license serial number.

#### Cloud-based

Enable this option only if you are using the cloud-based Back-Office. If your Veloce Back-Office is installed on a PC on your local network, this option needs to be disabled.

#### Workstation theme

Select between the various color schemes that will apply to the workstation.

#### Auto-Connect

Enable this option to have the Veloce POS application connect automatically to the Veloce Back-Office when the application is launched. If this option is left disabled, the workstation will not connect automatically to the Veloce Back-Office when the application is launched. Instead, you will need to press a "CONNECT" button to manually connect.

***

### Connection credentials

![](https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2FsO0yTSOooSW2XCzNXBTc%2F04f-Credentials.png?alt=media\&token=620d43c8-01e3-4206-8cd6-37de425decfa)

#### Username

Enter the username to connect to the Veloce Back-Office, as configured in Setup / Utilities > Configuration > System Configuration... > Misc. > Modern Workstation > UserName.

#### Password

Enter the password to connect to the Veloce Back-Office, as configured in Setup / Utilities > Configuration > System Configuration... > Misc. > Modern Workstation > Password.

#### Forced IP

In this field, type the IP address that the Veloce POS application should use to connect to the Veloce Back-Office. This is required only if your Veloce Back-Office PC has more than one Ethernet adapter or uses multiple virtual adapters, resulting in the same PC having multiple IP addresses.

***

### Hardware

![](https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2F8nfvtWWg5WQ3pIjlHm4k%2F04g-Hardware.png?alt=media\&token=3560de7b-55f9-4400-bef9-877486d93262)

#### Scanner

Enable/Disable this option to turn the barcode scanner on or off.

#### Printer

Enable/Disable this option to turn the built-in printer on or off.

#### Tear paper prompt

Enable this option to have the application stop printing and notify the user when a check/receipt needs to be torn from the built-in printer. If this option is disabled, the printer will briefly pause between each printout but will automatically resume printing without notifying the user.

#### Payment

Enable this option to use the terminal as a payment device.

#### Card Reader

Enable/Disable this option to turn the magnetic card reader on or off. This only affects non-payment cards, like employee cards. Even of this option is disabled, the magnetic card reader will still be usable as a fall-back reader for payments cards (debit and credit).

#### Mifare Reader

Enable/Disable this option to turn the Mifare reader (contactless reader) on or off. This only affects non-payment cards, like employee cards. Even of this option is disabled, contactless payment will still be available.

***

### Miscellaneous options

## &#x20;![](https://1156452535-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FNjXj7M9eIjDUG86HsSCs%2Fuploads%2FJpVBKxuakB7PO5v58prw%2F04h-MiscOptions.png?alt=media\&token=544ced84-9ac5-404b-a75c-bf324163452c)

#### Automatic reboots

Enable or disable up to two scheduled automatic reboots. The reboot time can be set to 15 minutes increments.

#### Run on startup

Enable this option to automatically start the Veloce POS app when the terminal powers on.
